MSI MAG Coreliquid 240R V2 White ARGB 240mm CPU Liquid Cooler
Overview :
NEXT-GEN AMD SOCKET AM5 SUPPORT
AMD Socket AM5 (LGA 1718) is the next-generation socket designed to support next-generation AMD Ryzen™ 7000 desktop processors (Zen 4).
AMD Socket AM5 uses the same liquid cooler bracket as Socket AM4*.
This allows you to upgrade to and enjoy AM5 without buying a new liquid cooler.
*Requires motherboard’s dedicated AMD Socket AM5 backplate.
POWERED BY MSI
Create and establish the most powerful setup with Powered by MSI products, including PC case, motherboard, liquid cooler, graphics card, and power supply unit.
HIGH THERMAL DISSIPATION
A split pathway through the radiator rapidly dissipates heat, cooled liquid is then pumped back into the loop.
LGA 1700 COMPATIBLE
The MSI MAG Coreliquid 240R V2 White liquid cooler provides out of box support for LGA 1700.
MORE SILENCE THAN EXPECTED
MSI MAG Coreliquid 240R V2 White’s noise level is significantly lower than that of competitor’s by 10%
PUMP MOTOR RESONANCE ELIMINATION
A durable three phase motor at the core of the pump generates minimal vibrations for long-lasting operation.
RADIATOR PUMP DESIGN
The pump has been integrated into the radiator for sound dampening and noise reduction.
Additionally, placing the pump into the radiator also increases the pump’s life expectancy by moving it away from the heat source.
EXTENSIVE COMPATIBILITY
Robust yet built for flexibility, MSI MAG Coreliquid 240R V2 White has been designed with a secure installation bundle with compatibility on a number of Intel and AMD motherboards.
ROTATABLE BLOCKHEAD
Mount the cold plate at any orientation, turn the blockhead up to 270 degrees, and keep it upright.
Specifications :
| RADIATOR SIZE | 240mm |
| RADIATOR DIMENSIONS (WXDXH) | 274 x 120 x 27mm / 10.79 x 4.7 x 1.06 inches |
| NUMBER OF FANS | 2 |
| FAN DIMENSIONS (WXDXH) | 120 x 120 x 25mm / 4.7 x 4.7 x 0.98 inches |
| FAN SPEED | 500 ~ 2000 RPM |
| FAN AIR FLOW | 21.63 ~ 78.73 CFM |
| FAN BEARING | Two Ball Bearing |
| FAN LIFE EXPECTANCY | 70,000 hours |
| FAN RATED CURRENT | 0.15 A |
| FAN POWER CONSUMPTION | 1.8 W |
| PWM MODE | YES |
| CABLE LENGTH (PWM CABLE) | 550 / 350mm; 21.65 / 13.78 inches |
| FAN LIGHTING | ARGB |
| PUMP LIFE EXPECTANCY | 100,000 hours |
| PUMP NOISE LEVEL | 18 dBA |
| PUMP POWER CONSUMPTION | 4.08W |
| PUMP SPEED | 4200 RPM +-10% |
| COLD PLATE MATERIAL | Copper |
| BLOCK DIMENSIONS (WXDXH) | 80.57x 66.82 x 48.58mm |
| INTEL SOCKET SUPPORT | LGA 1150/1151/1155/1156/1200/1700 LGA 1366/2011/2011-3/2066 |
| AMD SOCKET SUPPORT | AM5/AM4/FM2+/FM2/FM1/AM3+/AM3/AM2+/AM2 |
