NZXT H9 Elite Black Dual-Chamber Mid-Tower Airflow Case
Features :
- Unique uninterrupted glass panel for a clear view of the interior
- Intuitive cable management and dual chamber design
- Room for ten fans or three 360mm Radiators
- Perforated top panel for enhanced cooling
- Direct airflow to the GPU for handling high-powered components
- Enhanced experience with other products from the NZXT ecosystem
- Includes four F Series 120mm Quiet Airflow fans
Overview :
The NZXT H9 Elite Black ATX Mid Tower Cabinet is designed to cool off powerful GPUs with its expansive thermal capabilities, featuring the capacity for ten fans and numerous 360mm radiator mounting options and the perforated top panel takes cooling even further.
GPU Capacity
The NZXT H9 Elite Black ATX Mid Tower Cabinet has 435mm of GPU clearance, offering room for the latest NVIDIA 40 Series and AMD 7000 Series cards.
Fan Capacity
The NZXT H9 Elite Black ATX Mid Tower Cabinet has room for 10 fans. With the capacity for 3x120mm fans on the side, 3 x 120mm or 2x140mm on the top and bottom, and 1 x120mm on the rear.
Radiator Capacity
The NZXT H9 Elite Black ATX Mid Tower Cabinet has room for up to a 360mm radiator on the top, bottom, or side, and up to a 120mm radiator on the rear.
Specifications :
Key Specs | |
Motherboard Support | Mini-ITX, Micro-ATX, ATX |
Enclosure Type | Mid-Tower |
Case Material | SGCC Steel, Tempered Glass |
Fan Support | |
Side | 3 x 120mm |
Top | 3 x 120mm / 2 x 140mm |
Bottom | 3 x 120mm / 2 x 140mm |
Rear | 1 x 120mm |
Filters | All Air Intakes |
Dimensions | |
Height | 495mm (With Feet) |
Width | 290mm |
Depth | 466mm |
Weight | 13.1 kg |
Radiator Support | |
Side | Up to 360mm |
Top | Up to 360mm |
Bottom | Up to 360mm |
Rear | Up to 120mm |
Compatibility & Clearance | |
CPU Cooler Clearance | Up to 165mm |
GPU Clearance | Up to 435mm |
PSU Clearance | 200mm |
Cable Management | 91mm |
Fan Specs | |
Model | F120Q (Case Version) |
Speed | 1200 ± 240RPM |
Airflow | 62.18 CFM |
Static | 1.05 mm – H2O |
Noise | 25.1 dBA |
Fan Connector | 3-pin |
Expansion Slots | |
Standard | 7 |
Vertical | 0 |
Fan Specs | |
Model | F120RGB Duo |
Speed | 500 ± 1800RPM |
Airflow | 48.58 CFM |
Static | 2.42mm – H2O |
Noise | 29 dBA |
Fan Connector | 4-pin |
Drive Bays | |
2.5″ | 4+2 |
3.5″ | 2 |
Warranty | 2 Years |
