MSI MAG B850 Tomahawk Max WiFi DDR5 AMD AM5 ATX WiFi 7 PCIe 5.0 Gaming Motherboard-Supports Ryzen 7000 / 8000 / 9000 Series Processors :
Overview :
The MSI MAG B850 Tomahawk Max WiFi is a feature-packed full-size ATX motherboard built on AMD’s B850 chipset, designed for AM5 Ryzen 7000/8000/9000 series processors. Ideal for gamers and enthusiasts, it delivers high-end capabilities such as PCIe 5.0 graphics, Gen5 M.2 storage, DDR5 overclocking to 8400+ MT/s, Wi-Fi 7/Bluetooth 5.4, 5 Gigabit LAN, robust 12+2+1 power design, and advanced thermal architecture to support sustained performance and high-end builds.
Features :
- Supports Ryzen 7000/8000/9000 series processors in AM5 socket
- DDR5 support up to 8400+ MT/s (OC), maximum 256 GB across 4 DIMMs
- 12+2+1 Duet Rail VRM with 60A power stages and dual 8-pin CPU power
- PCIe 5.0 x16 slot reinforced with Steel Armor
- Dual-Gen M.2 slots: 1× Gen5 x4 + 1× Gen4 x4 with thermal shields
- 5 Gigabit Ethernet LAN featuring Realtek 8126 chipset
- Integrated Wi-Fi 7 and Bluetooth 5.4 for high-speed wireless
- USB 3.2 Gen2×2 Type-C (20 Gbps), USB-A Gen2/Gen1, and USB 2.0 ports
- HDMI 2.1 and DisplayPort 1.4 for Ryzen APU display output
- Realtek ALC897 7.1-channel HD audio with Audio Boost
- Extended heatsinks, 7 W/mK thermal pads, and 6-layer PCB for optimal cooling
- EZ Debug LED, Flash BIOS, Clear CMOS, and reinforced clips for easy builds
- Includes water-pump and multiple fan headers for flexible cooling setup
Specifications :
| Model | MSI MAG B850 Tomahawk Max WiFi |
| Form Factor | ATX (305 × 244 mm) |
| Chipset | AMD B850 |
| CPU Support | Ryzen 7000 / 8000 / 9000 Series |
| Memory Support | 4× DDR5 DIMMs, up to 8400+ MT/s (OC), 256 GB max |
| VRM Design | 12+2+1 Duet Rail, 60A power stages, dual 8-pin EPS |
| PCIe Slots | 1× PCIe 5.0 x16 (Steel Armor), 1× PCIe 4.0 x4, 2× PCIe x1 |
| M.2 Slots | 1× Gen5 x4 + 1× Gen4 x4 (both with thermal shields) |
| SATA Ports | 4× SATA III 6 Gb/s (RAID 0/1/10 supported) |
| LAN | Realtek 8126 5 Gb Ethernet |
| Wireless | Wi-Fi 7 + Bluetooth 5.4 |
| Rear USB Ports | 1× USB-C 20 Gbps, 3× USB-A 10 Gbps, 2× USB-A 5 Gbps, 2× USB 2.0 |
| Front USB Headers | 1× USB-C 20 Gbps, 2× USB-A 10 Gbps, 2× USB 2.0 |
| Display Outputs | HDMI 2.1, DisplayPort 1.4 |
| Audio Codec | Realtek ALC897, 7.1 HD Audio with Audio Boost |
| Cooling & Build | Extended heatsinks, 7 W/mK pads, 6-layer PCB |
| Fan Headers | Multiple PWM/water-pump connectors |
| DIY Tools | EZ Debug LEDs, EZ Clip, Flash BIOS, Clear CMOS |
| Warranty | 3 Years |
