MSI B860 Gaming Plus WiFi DDR5 Intel LGA 1851 ATX WiFi 7 PCIe 5.0 Gaming Motherboard :
Overview :
The MSI B860 Gaming Plus WiFi is a performance-focused ATX motherboard designed for Intel’s latest 14th Gen Core Ultra processors on the LGA 1851 socket. MSI B860 Gaming Plus WiFi Featuring next-gen support like PCIe 5.0, DDR5 memory up to 8800+ MT/s, Gen5 M.2 storage, Wi-Fi 7, and 5G LAN, it’s built for gamers and power users who demand speed, stability, and future-ready connectivity. Its robust 12-phase power delivery and extended cooling ensure reliable performance under heavy loads.
Features :
Supports Intel Core Ultra (14th Gen) processors on LGA 1851 socket
12-phase Duet Rail VRM design ensures stable power delivery
Supports DDR5 memory up to 8800+ MT/s (OC), up to 256 GB
PCIe 5.0 x16 slot with Steel Armor for high-bandwidth GPU support
Triple M.2 slots including 1× Gen5 x4 with Shield Frozr cooling
Built-in Wi-Fi 7 and Bluetooth 5.4 for ultra-fast wireless
5 Gigabit LAN for high-speed wired connectivity
Thunderbolt 4 Type-C port with 40 Gbps and 8K video output
HDMI 2.1 and DisplayPort 1.4 for integrated graphics
Realtek ALC897 7.1-channel audio with Audio Boost
EZ Debug LED, M.2 Clip, Flash BIOS Button, and Clear CMOS
Optimized cooling with extended heatsinks and 6-layer PCB
Specifications :
| Model | MSI B860 Gaming Plus WiFi |
| Form Factor | ATX (305 × 244 mm) |
| Chipset | Intel B860 |
| CPU Socket | LGA 1851 |
| CPU Support | Intel Core Ultra (14th Gen and newer) |
| Memory Support | 4× DDR5 DIMM, up to 8800+ MT/s (OC), 256 GB max |
| VRM Design | 12-phase Duet Rail |
| PCIe Slots | 1× PCIe 5.0 x16, 1× PCIe 4.0 x16, 2× PCIe x1 |
| M.2 Slots | 1× Gen5 x4, 1× Gen4 x4, 1× Gen4 x2 (all with heatsinks) |
| SATA Ports | 4× SATA III 6Gb/s (RAID 0/1/5/10) |
| LAN | 5 Gigabit Ethernet |
| Wireless | Wi-Fi 7 + Bluetooth 5.4 |
| Rear USB Ports | 1× Thunderbolt 4 Type-C, 1× USB 10Gbps, 2× USB 5Gbps, 2× USB 2.0 |
| Front USB Headers | 1× USB-C 10Gbps, 2× USB 5Gbps, 2× USB 2.0 |
| Display Outputs | HDMI 2.1, DisplayPort 1.4 |
| Audio | Realtek ALC897, 7.1 HD Audio with Audio Boost |
| Cooling | Extended heatsinks, 7W/mK thermal pads, 6-layer PCB |
| Special Features | EZ M.2 Clip, Flash BIOS Button, Clear CMOS, Debug LEDs |
| Warranty | 3 Years |
