MSI MAG PANO M100R PZ WHITE Mid Tower Cabinet ATX Support, Front & Side Mesh Panel, USB Type C, Up To 360 mm Radiator Support
Overview:
The MSI MAG PANO M100R PZ WHITE is a modern Mid Tower PC cabinet built to deliver superior thermal performance, visual elegance, and builder-friendly features. Designed with a striking 270° panoramic tempered glass design and enhanced with mesh front and side panels, it promotes optimal airflow for high-performance gaming setups. This chassis supports ATX, Micro-ATX, and Mini-ITX motherboards, and features pre-installed ARGB fans, USB Type-C front I/O, MAG PANO M100R PZ WHITE and radiator support up to 360mm. It’s the perfect choice for gamers and creators seeking clean aesthetics, high customizability, and next-gen cooling performance. MAG PANO M100R PZ WHITE
Key Features:
270° Panoramic Tempered Glass side and front panel for a stunning hardware showcase
Optimized Airflow Design with mesh front and side intake for better thermal control
Supports ATX, Micro-ATX, Mini-ITX Motherboards including back-connect (PROJECT ZERO) support
Pre-installed ARGB Fans: 3 x 120mm side (reverse-blade) + 1 x 120mm rear
USB 3.2 Gen 2×2 Type-C Front I/O for high-speed data and power delivery
Tool-less Design for quick and easy installation of side, front, and top panels
Up to 360mm Radiator Support on top, side, or bottom for extreme cooling setups
Enhanced Cable Management with 33mm routing space and Velcro straps
Dust Protection with removable filters on top, side, and bottom
Specifications Table:
| Category | Details |
|---|---|
| Case Type | Mid Tower |
| Color | White |
| Material | Steel Frame, Tempered Glass Panels |
| Motherboard Support | ATX / Micro-ATX / Mini-ITX (Back-connect support included) |
| Side Panel | 270° Panoramic Tempered Glass |
| Front Panel | Mesh with ARGB intake |
| Expansion Slots | 7 |
| Drive Bays | 1 x 2.5″, 1 x 2.5″/3.5″ Combo |
| GPU Clearance | Up to 390mm |
| CPU Cooler Clearance | Up to 175mm |
| PSU Clearance | Up to 200mm |
| Pre-installed Fans | 3 x 120mm ARGB Reverse Blade (Side), 1 x 120mm ARGB (Rear) |
| Fan Support | Top/Side/Bottom: 3 x 120mm or 2 x 140mm |
| Radiator Support | Up to 360mm (Top, Side, Bottom) |
| Dust Filters | Removable (Top, Side, Bottom) |
| Front I/O Ports | 1 x USB 3.2 Gen 2×2 Type-C, 1 x USB 3.2 Gen 1 Type-A, HD Audio, LED Switch |
| Cable Management | 33mm clearance, Velcro straps pre-installed |
| ARGB Control | 1-to-4 ARGB + PWM Hub included |
| Tool-less Design | Yes (Side, Top, and Front Panels) |
| Dimensions (L x W x H) | 440mm x 235mm x 405mm |
| Net Weight | 8.66 kg |
| Warranty | 1-Year Limited Warranty |
