ASROCK Z890 Lightning WIFI ATX Motherboard (Intel Socket LGA 1851, DDR5, Wi-Fi 7)
Feature:
- ASRock Z890 Lightning WIFI Supports Intel® Core™ Ultra Processors (Series 2)(LGA1851)
- 16+1+1+1+1 Power Phase, Dr.MOS for VCore+GT
- ASROCK Z890 Lightning WIFI has 4 x DDR5 DIMMs Supports Dual Channel, up to 9066+ (OC)
- 1 PCIe 5.0 x16, 2 PCIe 4.0 x4, 1 PCIe 4.0 x1
- Graphics Output Options: 1 HDMI, 1 DisplayPort,
- 2 Thunderbolt™ 4 Type-C
- Realtek ALC897 7.1 CH HD Audio Codec, Nahimic Audio
- 4 SATA3 1 Blazing M.2 (PCIe Gen5 x4) 2 Hyper M.2 (PCIe Gen4 x4) 1 Hyper M.2 (PCIe Gen4 x4 & SATA3)
- 2 Thunderbolt™ 4 Type-C (Rear) 1 USB 3.2 Gen2x2 Type-C (Front), 1 USB 3.2 Gen2 Type-A (Rear), 6 USB 3.2 Gen1 (2 Rear, 4 Front), 8 USB 2.0 (4 Rear, 4 Front)
- Realtek 2.5G LAN
- 802.11axe Wi-Fi 6E + Bluetooth
- Supports BIOS Flashback, Memory OC Shield, M.2 Bottom Heatsink
16+1+1+1+1 Power Phase Design
ASROCK Z890 Lightning WIFI Featuring sturdy components and completely smooth power delivery to the CPU. Plus, it offers unmatched overclocking capabilities and enhanced performance with the lowest temperature for advanced gamers as well.
Dr. MOS
ASROCK Z890 Lightning WIFI’s Dr.MOS is the integrated power stage solution which is optimized for synchronous buck-set down voltage applications! Compared to traditional discrete MOSFETs, it intelligently delivers higher current for each phase, thus providing improved thermal result and superior performance.
Hi-Density Power Connector
CPU overclocking requires higher current, ASRock Hi-Density Power connectors is able to withstand current higher traditional CPU 8-pin and ATX 24-pin connector, giving a more stable system as well as lowering the risk of fire under heavy overclocking.
Specification:
| Unique Feature | Superb Productivity |
| – PCIe Gen5 (Graphics, M.2) | |
| – Dual Channel DDR5 | |
| – Thunderbolt™ 4 Type-C Ports (40 Gb/s) | |
| Rock-Solid Durability | |
| – 16+1+1+1+1 Power Phase, Dr. MOS for VCore+GT with Enlarged Heatsink Armor | |
| – Memory OC Shield | |
| – Flexible Integrated I/O Shield | |
| Ultrafast Connectivity | |
| – 2.5G LAN, 802.11axe Wi-Fi 6E Module | |
| EZ Update | |
| – BIOS Flashback Button | |
| – ASRock Auto Driver Installer | |
| EZ Troubleshooter | |
| CPU | – Supports Intel® Core™ Ultra Processors (Series 2) (LGA1851RL-ILM) |
| – Supports Intel® Hybrid Technology | |
| – Supports Intel® Turbo Boost Max 3.0 Technology | |
| – Supports Intel® Thermal Velocity Boost (TVB) | |
| – Supports Intel® Adaptive Boost Technology (ABT) | |
| – Integrated NPU for dedicated AI acceleration | |
| Chipset | – Intel® Z890 |
| Memory | Dual Channel DDR5 Memory Technology |
| – 4 x DDR5 DIMM Slots | |
| – Supports DDR5 non-ECC, un-buffered memory up to 9066MHz+(OC)* | |
| – Supports Clocked Unbuffered DIMM (CUDIMM) | |
| – Max. capacity of system memory: 256GB | |
| – Supports Intel® Extreme Memory Profile (XMP) 3.0x | |
| BIOS | – 256Mb AMI UEFI Legal BIOS with GUI support |
| Graphics | Intel® Xe LPG Graphics Architecture |
| – 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz | |
| – 1 x DisplayPort 1.4 with DSC (compressed), supports HDCP 2.3 and max. resolution up to 8K 60Hz / 5K 120Hz | |
| Audio | 7.1 CH HD Audio (Realtek ALC897 Audio Codec) |
| – Nahimic Audio | |
| LAN | – 2.5 Gigabit LAN 10/100/1000/2500 Mb/s |
| – Dragon RTL8125BG | |
| – Supports Dragon 2.5G LAN Software | |
| – Smart Auto Adjust Bandwidth Control | |
| – Visual User Friendly UI | |
| – Visual Network Usage Statistics | |
| – Optimized Default Setting for Game, Browser, and Streaming Modes | |
| – User Customized Priority Control | |
| Wireless LAN | 802.11axe Wi-Fi 6E Module |
| – Supports IEEE 802.11a/b/g/n/ac/ax/axe | |
| – Supports Dual-Band 2×2 with extended 6GHz band* support | |
| – 2 antennas to support 2 (Transmit) x 2 (Receive) diversity technology | |
| – Supports Bluetooth 5.3 | |
| – Supports MU-MIMO | |
| Slots | CPU: |
| – 1 x PCIe 5.0 x16 Slot (PCIE1), supports x16 mode* | |
| Chipset: | |
| – 2 x PCIe 4.0 x4 Slots (PCIE3 and PCIE4), support x4 mode* | |
| – 1 x PCIe 4.0 x1 Slot (PCIE2)* | |
| – 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module and Intel® CNVio/CNVio2 (Integrated WiFi/BT) | |
| Storage | CPU: |
| – 1 x Blazing M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen5x4 (128 Gb/s) mode* | |
| – 1 x Hyper M.2 Socket (M2_2, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode* | |
| Chipset: | |
| – 1 x Hyper M.2 Socket (M2_3, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode* | |
| – 1 x Hyper M.2 Socket (M2_4, Key M), supports type 2230/2242/2260/2280 SATA3 6.0 Gb/s & PCIe Gen4x4 (64 Gb/s) modes* | |
| – 4 x SATA3 6.0 Gb/s Connectors | |
| RAID | Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices |
| – Supports RAID 0, RAID 1, RAID 5 and RAID 10 for M.2 NVMe storage devices | |
| USB | CPU: |
| – 2 x Thunderbolt™ 4 Type-C (Rear) | |
| Chipset: | |
| – 1 x USB 3.2 Gen2x2 Type-C (Front) | |
| – 1 x USB 3.2 Gen2 Type-A (Rear) | |
| – 6 x USB 3.2 Gen1 (2 Rear, 4 Front) | |
| – 8 x USB 2.0 (4 Rear, 4 Front) | |
| Connector | 1 x SPI TPM Header |
| – 1 x Power LED and Speaker Header | |
| – 1 x RGB LED Header* | |
| – 3 x Addressable LED Headers** | |
| – 2 x CPU Fan Connectors (4-pin) (Smart Fan Speed Control)*** | |
| – 5 x Chassis Fan Connectors (4-pin) (Smart Fan Speed Control)*** | |
| – 1 x AIO Pump Fan Connector (4-pin) (Smart Fan Speed Control)**** | |
| – 1 x 24 pin ATX Power Connector | |
| – 2 x 8 pin 12V Power Connectors (Hi-Density Power Connector) | |
| – 1 x Front Panel Audio Connector | |
| – 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) | |
| – 2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports) | |
| – 1 x Front Panel Type C USB 3.2 Gen2x2 Header (20 Gb/s) | |
| Rear Panel I/O | 2 x Antenna Ports |
| – 1 x HDMI Port | |
| – 1 x DisplayPort 1.4 | |
| – 2 x Thunderbolt™ 4 Type-C Ports (40 Gb/s for USB4 protocol; 40Gb/s for Thunderbolt™ protocol)* | |
| – 1 x USB 3.2 Gen2 Type-A Port (10 Gb/s) | |
| – 2 x USB 3.2 Gen1 Ports | |
| – 4 x USB 2.0 Ports | |
| – 1 x RJ-45 LAN Port | |
| – 1 x BIOS Flashback Button | |
| – HD Audio Jacks: Line in / Front Speaker / Microphone | |
| Software and UEFI | Software |
| – ASRock Motherboard Utility (A-Tuning) | |
| – ASRock Dragon 2.5G LAN Software | |
| – ASRock Polychrome SYNC* | |
| UEFI | |
| – ASRock EZ Mode | |
| – ASRock Full HD UEFI | |
| – ASRock My Favorites in UEFI | |
| – ASRock Auto Driver Installer | |
| – ASRock Instant Flash | |
| Accessories | 2 x SATA Data Cables |
| – 2 x ASRock WiFi 2.4/5/6 GHz Antennas | |
| – 1 x Screw for M.2 Socket | |
| – 1 x Standoff for M.2 Socket | |
| Form Factor | ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cm |
| – 2oz Copper PCB |
