FEATURES
- 80 PLUS® Bronze certified
- Fixed cables
- Tight Voltage Regulation
- 105 °C Japanese Capacitor
- S2FC – Smart and Silent Fan Control
- FDB Fan
- Gold plated connectors
- 5 years warranty
| Model | S12II-430 |
| 80PLUS® | Bronze |
| Form Factor | Intel ATX 12 V |
| Dimensions | 150 mm (W) x 140 mm (L) x 86 mm (H) |
| Fan Information | |
| Fan Size | 120 mm |
| Fan Control | Seasonic S2FC |
| Fan Bearing | Fluid Dynamic Bearing |
| Life Expectancy | 50,000 hours at 40 °C, 15 % – 65 % RH |
| Cable Information | |
| Modularity | Fixed cable |
| Cable type | Flat black cables |
| Electrical Features | |
| Operating Temperature | 40 °C |
| MTBF @ 25 °C, excl. fan | 100,000 hours |
| AC Input | Full Range |
| Protection | OPP, OVP, UVP, SCP |
| Safety and Environmental | |
| Safety and EMC | cTUVus, TUV, Gost-R, UkrTEST, CB , BSMI, Semko, CCC, CE, FCC, C-tick |
| Environmental Compliance | Energy Star, RoHS, WEEE, REACH |
| Warranty | 5 Years |
80 PLUS®BRONZEThe 80 PLUS® Bronze certification indicates that a high percentage of the electricity is converted into useful power, therefore there is less heat lost and more money saved on the electricity bill. |  |
 | S2FC – SMART AND SILENT FAN CONTROLThe intelligent thermal circuit feature is designed to find the optimal balance between the necessity to cool the components and the need to run the power supply in the most silent manner possible. |
FLUID DYNAMIC FAN BEARINGHigh performance Fluid Dynamic Bearing (FDB) fans are designed to take advantage of the impact absorbance effects of oil. They are extremely reliable and generate considerably less operating noise and heat than ball bearing fans. The lubrication of the bearing surface reduces friction and vibration and therefore lowers overall power consumption. Due to the effortless, quieter rotations and its robust construction, this reliable fan technology also greatly increases the lifespan of the fan. |  |
