PNY Nvidia GeForce RTX 5080 OC 16GB GDDR7 Triple Fan Graphics Card :
Overview :
The PNY Nvidia GeForce RTX 5080 OC 16GB GDDR7 Triple Fan Graphics Card is engineered for high-performance gaming and professional workloads. Built on NVIDIA’s Blackwell architecture, PNY Nvidia GeForce RTX 5080 OC 16GB GDDR7 Triple Fan Graphics Card features 16GB of GDDR7 memory and 10,752 CUDA cores, delivering exceptional performance for demanding applications. The triple-fan cooling system ensures optimal thermal management, PNY Nvidia GeForce RTX 5080 OC 16GB GDDR7 Triple Fan Graphics Card support for DLSS 4 and real-time ray tracing provides immersive visuals.
Key Features :
NVIDIA Blackwell Architecture: Provides significant performance and efficiency improvements.
16GB GDDR7 Memory: Offers ample high-speed memory for demanding applications.
Triple-Fan Cooling System: Ensures efficient heat dissipation during intensive workloads.
DLSS 4 and Ray Tracing Support: Delivers realistic visuals and AI-accelerated performance.
PCIe 5.0 Compatibility: Supports the latest PCIe 5.0 interface for faster data throughput.
VelocityX Overclocking Software: Allows for performance tuning and system monitoring.
Specification Table :
| GPU Model | NVIDIA GeForce RTX 5080 |
| CUDA Cores | 10,752 |
| Base Clock | 2.30 GHz |
| Boost Clock | 2.73 GHz |
| Memory | 16GB GDDR7 |
| Memory Interface | 256-bit |
| Memory Speed | 30 Gbps |
| Memory Bandwidth | 960 GB/s |
| Ray Tracing Cores | 4th Generation |
| Tensor Cores | 5th Generation |
| Bus Interface | PCI Express 5.0 x16 |
| Display Outputs | 3 x DisplayPort 2.1b, 1 x HDMI 2.1b |
| Maximum Digital Resolution | 7680 x 4320 (8K UHD) |
| Multi-Display Support | Up to 4 displays |
| Power Consumption (TDP) | 360W |
| Recommended PSU | 850W |
| Power Connector | 1 x 16-pin (12V-2×6) |
| Cooling System | Triple-Fan Cooling |
| Dimensions (L x W x H) | 329.7 x 137.8 x 67.8 mm |
| Slot Size | 3-slot |
| DirectX Support | DirectX 12 Ultimate |
| OpenGL Support | OpenGL 4.6 |
| Vulkan API | Vulkan 1.4 |
| Operating System Support | Windows 11 / Windows 10 64-bit (v1809 or later) |
| Additional Features | NVIDIA DLSS 4, NVIDIA Reflex, NVIDIA Broadcast, NVIDIA Studio Drivers |
| Accessories Included | User Manual, 3 x 8-pin-to-16-pin cable |
| Warranty | 3 Years Standard |
