Gigabyte Nvidia GeForce RTX 5070 Ti Gaming OC 16GB GDDR7 Triple Fan Graphics Card :
Overview :
The Gigabyte Nvidia GeForce RTX 5070 Ti Gaming OC 16GB GDDR7 Triple Fan Graphics Card delivers exceptional performance for gamers and creators. Built on NVIDIA’s Blackwell architecture, Gigabyte Nvidia GeForce RTX 5070 Ti Gaming OC 16GB GDDR7 Triple Fan Graphics Card features 16GB of GDDR7 memory, DLSS 4, and advanced ray tracing capabilities. Gigabyte Nvidia GeForce RTX 5070 Ti Gaming OC 16GB GDDR7 Triple Fan Graphics Card WINDFORCE cooling system ensures optimal thermal performance, while RGB lighting and dual BIOS modes offer customization and flexibility.
Key Features :
NVIDIA Blackwell Architecture: Provides next-generation performance and efficiency.
16GB GDDR7 Memory: Ensures smooth multitasking and rendering with high-speed memory.
WINDFORCE Cooling System: Features triple Hawk fans, server-grade thermal conductive gel, and composite copper heat pipes for superior thermal management.
Dual BIOS (Performance/Silent): Allows users to switch between high-performance and quieter operation modes.
RGB Lighting: Customizable lighting to match your system’s aesthetics.
Reinforced Structure: Enhances structural integrity and prevents PCB flex.
Versatile VGA Holder: Provides additional support to prevent GPU sag.
4-Year Warranty: Offers extended protection with online registration.
Specifications :
| GPU Model | NVIDIA GeForce RTX 5070 Ti |
| CUDA Cores | 8,960 |
| Base Clock | 2,300 MHz |
| Boost Clock | 2,588 MHz |
| Memory | 16GB GDDR7 |
| Memory Interface | 256-bit |
| Memory Speed | 28 Gbps |
| Memory Bandwidth | 896 GB/s |
| Ray Tracing Cores | 4th Generation |
| Tensor Cores | 5th Generation |
| Bus Interface | PCI Express 5.0 x16 |
| Display Outputs | 3 x DisplayPort 2.1b, 1 x HDMI 2.1b |
| Maximum Digital Resolution | 7680 x 4320 |
| Multi-Display Support | Up to 4 displays |
| Power Consumption (TDP) | 300W |
| Recommended PSU | 750W |
| Power Connectors | 1 x 16-pin (12V-2×6) |
| Cooling System | Triple Fan (WINDFORCE) with Hawk Fans and Composite Heat Pipes |
| Dimensions (L x W x H) | 340 x 140 x 70 mm |
| Slot Size | Triple-slot |
| DirectX Support | DirectX 12 Ultimate |
| OpenGL Support | OpenGL 4.6 |
| Vulkan API | Vulkan 1.4 |
| Operating System Support | Windows 11 / 10, Linux |
| Additional Features | NVIDIA DLSS 4, NVIDIA Reflex, NVIDIA Broadcast, NVIDIA Studio Drivers |
| Accessories Included | User Manual, 1 x 12V-2×6 to 3 x PCIe 8-pin Adapter, VGA Holder |
| Warranty | 3 Years Manufacturer Warranty (+1 Years with Registration) |
