Cooler Master Elite 490 Black ARGB M-ATX Mini Tower Cabinet with High-Airflow Mesh Front, Tempered Glass Side Panel, Dual ARGB Fans, USB Type-C, Upto 360MM Radiator Support :
Overview :
The Cooler Master Elite 490 Black ARGB M-ATX Mini Tower Cabinet is designed for users who want the power of a high-end gaming PC inside a compact, modern chassis. Cooler Master Elite 490 Black ARGB M-ATX Mini Tower Cabinet With dual tempered-glass panels, a high-airflow mesh layout, and three pre-installed ARGB fans, Cooler Master Elite 490 Black ARGB M-ATX Mini Tower Cabinet delivers exceptional airflow and aesthetics right out of the box.
Key Features :
Dual Tempered Glass Panels: Front and side glass panels provide a showcase look for ARGB fans and internal components.
High Airflow Mesh Design: Optimized ventilation for lower temperatures in demanding gaming or multitasking workloads.
Pre-Installed ARGB Fans: Comes with 3 ARGB fans (2 side intake + 1 rear exhaust) ensuring balanced cooling from the start.
360mm Radiator Support: Top and bottom support for up to 360mm liquid coolers—rare for an M-ATX case.
Supports Full-Size GPUs: GPU clearance up to approx. 425mm allows installation of high-end graphics cards.
Modern I/O Panel: Includes USB Type-C, dual USB 3.0 Type-A ports, and a 3.5mm audio combo jack.
Up to 9 Fans Supported: Exceptional fan layout flexibility for advanced airflow customization.
PSU Support: Fits full-size ATX power supplies up to approx. 250mm.
Compact Yet Powerful Layout: Designed for Micro-ATX and Mini-ITX motherboards with exceptional cooling options.
Vertical Airflow Structure: Bottom-to-top airflow ensures optimized heat dissipation within small form factor builds.
Specifications Table :
| Model / SKU | E490-KHNN-S00 |
| Case Type | Mini Tower |
| Supported Motherboards | Micro-ATX, Mini-ITX |
| Materials | Tempered Glass (Front & Side), Steel Body |
| Dimensions | 434 × 218 × 414 mm |
| Internal Volume | Approx. 39.16 Liters |
| Expansion Slots | 5 |
| Drive Support | 1 × 3.5″ HDD (supports up to 2), 1 × 2.5″ SSD |
| Pre-Installed Fans | 3 × 120mm ARGB (2 side, 1 rear) |
| Fan Support | Top: 3 × 120mm / 2 × 140mm Bottom: 3 × 120mm Side: 2 × 120mm Rear: 1 × 120mm Max Total: 9 Fans |
| Radiator Support | Top: Up to 360mm Bottom: Up to 360mm Side: Up to 240mm |
| GPU Clearance | Up to ~425mm |
| CPU Cooler Clearance | Up to ~170mm |
| PSU Support | ATX, up to ~250mm |
| Front I/O | 1 × USB Type-C, 2 × USB 3.0 Type-A, 1 × 3.5 mm audio combo jack |
| Cooling Layout | Vertical bottom-to-top airflow |
| Warranty | 2 Years |
