Antec NE550M V2 80 Plus Bronze Power Supply :
Overview :
80 PLUS Bronze Certified
Up to 88% efficient, to reduce your electricity bill.
Japanese Heavy-duty Caps
Japanese High-performance capacitors ensure tightest DC stability and regulation.
Advanced Hybrid Cable Management
Improves airflow and reduces clutter.
120mm silent Fan
Whisper-quiet high-quality silent fan with long lifetime.
stealth flat cable
For easier & better cable management.
Specifications :
Model | NE550M V2 |
Type | ATX 12V 2.4 |
Modular | Semi-Modular |
Dimension | 140(L) x 150(W) x 86(H) |
Warranty | 5 years |
Input Voltage | 100-240 VAC |
Input Current | 8A-4A |
Input Frequency Range | 47Hz-63Hz |
PFC | Active PFC |
Power Good Signal | 100-500ms |
Efficiency | Up to 88% |
Protection | OCP / OVP / UVP / SCP / OPP / NLO |
Output Capacity | 550W |
Operation Temperature | 0-40°C |
Regulatory | cTUVus / TUV / CB[IEC62368 Compliant] / RCM / |
CE / CCC / BSMI / FCC | |
Fan | 120 mm Silence Fan |
Certifications | 80 Plus Bronze |
Connector | 1 x MB 24(20+4) Pin |
1 x 8(4+4) Pin EPS 12V | |
2 x 8(6+2) Pin PCI-E | |
5 x SATA | |
3 x Molex | |
Net Weight | 2.20 Kgs |
Gross Weight | 2.33 Kgs |
UPC# | 0-761345-10573-6 |
