Kingston NV1 500GB M.2 NVMe Internal SSD :
Efficient performance for thinner notebooks and systems
Kingston NV1 500GB M.2 NVMe PCIe SSD is a substantial storage solution that offers read/write1 speeds up to 2,100/1,700MB/s, which is 3 to 4 times faster than a SATA-based SSD, and 35 times faster than a traditional hard drive. NV1 works with lower power, lower heat, and quicker loading time. The efficient performance and single-sided M.2 2280 (22x80mm) design makes NV1 ideal for thin notebooks and systems with limited space.
Available in capacities from 500GB – 2TB2 to give you all the space you need for applications, documents, photos, videos, and more.
- NVMe PCIe SSD Performance
- 3-year limited warranty
- Up to 2,100MB/s Read, 1,700MB/s Write
- Product contains drive only; cloning software not included.
NVMe PCIe Performance
Kingston NV1 500GB M.2 NVMe Offers read/write speeds up to 2,100/1,700MB/s
Ideal for systems with limited space
Kingston NV1 500GB M.2 NVMe Easily integrate into designs with M.2 connectors. Perfect for thin laptops and small form factor PCs.
Available in a range of capacities up to 2TB2 to meet your data storage requirements.
|Form Factor||M.2 2280|
|Interface||NVMe™ PCIe Gen 3.0 x 4 Lanes|
|Capacities2||250GB, 500GB, 1TB, 2TB|
|Sequential Read/Write1||250GB – 2100/1100MB/s|
|500GB, 1TB, 2TB – 2100/1700MB/s|
|Endurance3||250GB – 60TBW|
|500GB – 120TBW|
|1000GB – 240TBW|
|2000GB – 480TBW|
|Power Consumption||250GB: 5mW Idle / 85.5mW Avg / 0.99W (MAX) Read / 1.5W (MAX) Write|
|500GB: 5mW Idle / 205mW Avg / 1.1W (MAX) Read / 3.3W (MAX) Write|
|1000GB: 5mW Idle / 220mW Avg / 1.1W (MAX) Read / 3.3W (MAX) Write|
|2000GB: 5mW Idle / 340mW Avg / 1.1W (MAX) Read / 3.3W (MAX) Write|
|Dimensions||22mm x 80mm x 2.1mm|
|Weight||7g (All capacities)|
|Vibration Operating||2.17G (7-800 Hz)|
|Vibration Non-operating||20G (20-1000Hz)|
|Warranty/Support4||Limited 3-year warranty with free technical support|
