Deepcool SC790 PWM & ARGB Hub :
The DeepCool SC790 PWM & ARGB Hub 2-in-1 PWM & RGB hub provides fan and lighting control for up to 6 total PWM ARGB fans simultaneously while occupying minimal headers on a motherboard.
Overview :
PWM & ARGB SPLITTER HUB
The Deepcool SC790 PWM & ARGB Hub connects to a 3-pin 5V ARGB header and 4-pin PWM header on a motherboard and extends their signal to connect up to 6 PWM ARGB fans for total synchronization. The included SATA interface ensures stable continuous power for all connected devices.
- The compact and sturdy case is also magnetic, allowing it to be conveniently tucked away behind the motherboard tray or positioned anywhere else.
- Supports ASUS Aura, GIGABYTE Fusion, MSI Mystic Light, and ASRock Polychrome.
- This product is NOT compatible with 12V 4-Pin RGB devices.
Specifications :
| Product Dimension | 102×60×17 mm |
| Net Weight | 69g |
| Port Type | ARGB-3Pin & PWM-4 Pin |
| Fan Ports | 6 Ports x 4Pin PWM |
| Length of Fan Connector Cable | 24AWG 500 mm |
| Fan Rated Voltage | 12V DC |
| Fan Rated Current | 2.0A(1Port) / Total 4.5A(6Ports) |
| RGB Ports | 6 Ports x 3Pin Addressable RGB |
| Length of ARGB Connector Cable | 24 AWG 538mm (Asus Asrock MSI) +50mm (Gigabyte) |
| RGB Rated Voltage | 5V DC |
| RGB Safety Current | 2.0A(1Port) / Total 4.5A(6Ports) |
| Power Connector | SATA Power |
| Power Safety Current | 4.5A Max |
| Mounting Method | Magnetic |
| Product Color | Black |
| Warranty | 1 Year |
